Heat pump water heaters

Air-Source Heat Pump Water Heater

B.J.Huang , Director, New Energy Center
Professor, Department of Mechanical Engineering
National Taiwan University, Taipei, Taiwan



HP-1500

Unit Specification

capacity: 7.9 gallons (~ 30 liters)
Maximum water temperature: 167℉ (75℃)
Output: 5,500W (Hot water)
Output: 15,000BTUs (Cool air)
COP: 3.1 (Coefficient Of Performance)
Recovery: 39.6 gallons (~150 liters) per hours at 167℉ (75℃)*
Dehumidification: 0.39 gallons (1.5 liters) per hour at 80% RH *
Heat exchange: Copper
Refrigerant: R417a
All digital automatic control
* Results may vary depending on operating climate.

Electrical Specifications

Volts: 220V
Frequency: 60Hz
Power Consumption: 1,800W (ON mode)
Electric backup heating element: 2,400W
Dimensions

Height: 39" (100㎝)
Width: 23 5/8" (60㎝)
Depth: 15 3/4" (40㎝)
Weight: 88.18 Pounds (40kg)
Water Connection: Water in and out connections are fitted with 3/4" female pipe threads connections


---

HP-1000T

Unit Specification

Water tank capacity: 50 gallons (~ 200 liters)
Maximum water temperature: 167℉ (75℃)
Output: 3,500W (Hot water)
Output: 10,000 BTUs (Cool air)
COP: 3.0 (Coefficient Of Performance)
Recovery: 25 gallons (~100 liters) per hours at 140℉ (60℃)*
Dehumidification: 7.92 ~ 10.57 gallons (30 ~ 40 liters) per day at 80% RH *
Heat exchange: Copper
Refrigerant: R417A
All digital automatic control
* Results may vary depending on operating climate.

Electrical Specifications

Volts: 220V (also in 220V ~ 240V, 50Hz)
Frequency: 60Hz
Power Consumption: 1200W (ON mode)
Electric backup heating element: 2,400W
Dimensions

Height: 62.99" (160㎝)
Width: 23.62" (60㎝)
Depth: 15.57" (40㎝)
Weight: 132.28 Pounds (60kg)
Water Connection: Water in and out connections are fitted with 3/4" female pipe threads connections


---

HP-1000

Unit Specification

Water tank capacity: 7.9 gallons (~ 30 liters)
Maximum water temperature: 140℉ (60℃)
Output: 3,500 (Hot water)
Output: 10,000 BTUs (Cool air)
COP: 3.0 (Coefficient Of Performance)
Recovery: 25 gallons (~100 liters) per hours at 167℉ (75℃)*
Dehumidification: 7.92 ~ 10.57 gallons (30 ~ 40 liters) per day at 80% RH *
Heat exchange: Copper
Refrigerant: R417A
All digital automatic control
* Results may vary depending on operating climate.

Electrical Specifications

Volts: 220V (also in 220V ~ 240V, 50Hz)
Frequency: 60Hz
Power Consumption: 1200W (ON mode)
Electric backup heating element: 2,400W
Dimensions

Height: 47.24" (120㎝)
Width: 19.69" (50㎝)
Depth: 11.81" (30㎝)
Weight: 88.18 Pounds (40kg)
Water Connection: Water in and out connections are fitted with 3/4" female pipe threads connections


---

HP-500

Unit Specification

Water tank capacity: 50 gallons (~ 200 liters)
Maximum water temperature: 140℉ (60℃)
Output: 2,000W (Hot water)
Output: 5,500BTUs (Cool air)
COP: 2.8 (Coefficient Of Performance)
Recovery: 13.2 gallons (~50 liters) per hours at 140℉ (60℃)*
Dehumidification: 5.28 ~ 6.60 gallons (20 ~ 25 liters) per day at 80% RH *
Heat exchange: Copper
Refrigerant: R134A
All digital automatic control
* Results may vary depending on operating climate.

Electrical Specifications

Volts: 120V (also in 220V ~ 240V, 50Hz)
Frequency: 60Hz
Power Consumption: 650W (ON mode)
Electric backup heating element: 600W
Dimensions

Height: 63" (160㎝)
Width: 23 5/8" (60㎝)
Depth: 15 3/4" (40㎝)
Weight: 127.87 Pounds (58kg)
Water Connection: Water in and out connections are fitted with 3/4" female pipe threads connections


---

HP-8000 (Commercial)

Unit Specification

Buffer water tank capacity: 50 gallons (~ 200 liters)
Maximum water temperature: 167℉ (75℃)
Output: 25,600W (Hot water)
Output: 60,000BTUs (Cool air)
Recovery: 158.5 gallons (~600 liters) per hours at 140℉ (60℃)*
Heat exchange: Copper
Refrigerant: R417a
All digital automatic control
* Results may vary depending on operating climate.

Electrical Specifications

Volts: 220V
Frequency: 60Hz
Power Consumption: 8,000W (ON mode)
Dimensions

Height: 45.31" (115㎝)
Width: 31.52" (80㎝)
Depth: 47.28" (120㎝)
Weight: 551.15 Pounds (250kg)

---
